GSMR1098 - GSMR7098

Spring Mount Rivet

Back to

Sizes in mm

Click here for a detailed view

P/N.	Article No.	Material	Color	A	B	C	D	E	L	Top Panel Thickness	Bottom Panel Thickness	Packing Unit	PDF	3D
43493	GSMR1098	PA66 UL94V2	Natural	1.4	4.6	5.6	6.8	8,2	11.3	0.5-2.5	1.2	1000
43494	GSMR2098	PA66 UL94V2	Black	1.7	4.6	5.6	6.8	8,5	11.7	0.5-2.5	1.6	1000
43495	GSMR3098	PA66 UL94V2	Gray	1.7	5.1	6.1	7.3	9,0	12.2	1.0-3.0	1.6	1000
43496	GSMR4098	PA66 UL94V2	White	1.4	4.6	5.6	6.8	8,2	11.3	0.5-2.5	1.2	1000
43583	GSMR5098	PA66 UL94V2	Yellow	1.7	5.1	6.1	7.3	9,0	12.2	1.0-3.0	1.6	1000
43584	GSMR6098	PA66 UL94V2	Tan	1.4	4.6	5.6	6.8	8,2	11.3	0.5-2.5	1.2	1000
43585	GSMR7098	PA66 UL94V2	Blue	1.7	5.1	5.1	7.3	9,0	12.2	1.0-3.0	1.6	1000
